ROGER TECHNOLOGY R20 Swing Gate Motor | Up to 5m | 230v

ROGER TECHNOLOGY R20 Swing Gate Motor | Up to 5m | 230v

Swing Gates Operator
Code: R20*
  • From £341.92 Ex Vat
Item out of Stock   |   Usually dispatched within 24 hours
Loading...
Ask A Question
Tell A Friend
Price Match

Product Overview

The R20 Swing Gate Motor is a versatile and robust electromechanical operator designed for swing gates with leaves up to 5m. This 230V AC motor is irreversible and includes a microswitch for added reliability. Ideal for residential and commercial applications, the R20 motor ensures smooth and efficient gate operation.

Key Features

  • Suitable for swing gates with leaves up to 3.5m
  • 230V AC power supply
  • Irreversible motor with microswitch

Product Description

The R20 Swing Gate Motor is an electromechanical operator designed for swing gates. With its powerful 230V AC motor, the R20 can handle gate leaves up to 5m in length, depending on the chosen motor type. The motor is designed for long-lasting performance and includes a microswitch for reliable operation. It is available in different versions to suit various installation needs.

Specifications

SpecificationR20/300R20/500
Power line supply230V AC - 50Hz230V AC - 50Hz
Motor power supply230V AC230V AC
Power rating (W)200200
Frequency of use (%)4040
Thrust (N)25002500
Operating temperature (°C)-20 to +55-20 to +55
Protection levelIP44IP43
Reductor TypeIrreversibleIrreversible
Manoeuvre speed (cm/s)1.661.66
Opening time (s)1927
Stroke (mm)320520
Motor thermal protection (°C)150140
Incorporated condenser (µF)1515
Limit switchMicroswitch in opening (optional in closing)Microswitch in opening (optional in closing)
Encoder--
Maximum dimension product (L x W x H in mm)858.5 x 120 x 1651088.5 x 120 x 165
Product weight packed (Kg)9.210.7

Accessories

  • Standard: KT206: Kit of three hinge plates short to weld.
  • Other:
    • MC770: Kit optional microswitch in closing with cable for R20 series.
    • R99/C/001: Signboard "Automatic Opening".
    • MC780: Kit of 2 mechanical stops for R20 series.
    • KT202/R: Screw-welded short front bracket.
    • KT204/R: Screw-adjustable short rear bracket.
    • KT206/R: Kit of screw-adjustable short rear bracket and screw-welded short front bracket.
    • R99/C/001AL: Signboard "Automatic Opening" Aluminium version.

Applications

The R20 Swing Gate Motor is ideal for automating swing gates in residential and commercial settings. Its robust design and reliable performance make it suitable for a variety of environments, ensuring secure and efficient gate operation.
