- ROGER TECHNOLOGY BI/006 Series Bionik Brushless Barriers | 36V DC | Up to 6 Meters | Barrier Only
ROGER TECHNOLOGY BI/006 Series Bionik Brushless Barriers | 36V DC | Up to 6 Meters | Barrier Only
- From 2682,76 € 2235,63 € Ex Vat Ex Vat Inc Vat Inc Vat
- |
- |
- (%)
Product Overview
The BI/006 Series Bionik Brushless Barriers are designed for managing booms up to 6 meters, making them ideal for high-traffic zones and parking solutions. These 36V DC barriers are built for super intensive use, offering up to 4000 operating cycles daily. The BI/006 series features two versions, including the BI/006 with a painted RAL9006 cabinet and the BI/006/IS with a brushed stainless steel AISI 304 housing unit.
Variants
- BI/006 - Compatible with BA/90/3, BA/90/4, and BA/90/6 booms. Requires KT230 fixing plate.
- BI/006/IS - Stainless steel housing, compatible with BA/90/3, BA/90/4, and BA/90/6 booms. Requires KT230 fixing plate.
Key Features
- Intuitive operation
- Adaptable design
- Super intensive use capability
- Aesthetic finish
- High reliability and durability
- Battery backup available
Specifications
| Specification | BI/006 | BI/006/IS |
|---|---|---|
| Barriers | Up to 6 mt long | |
| Power Line Supply | 230V AC - 50 Hz | |
| Motor Power Supply | 36V DC | |
| Electrical Absorption | max. 15A | |
| Power Rating | 220W | |
| Frequency of Use | Super intensive use | |
| Torque | 10 - 300 N m | |
| Operating Temperature | -20 + 55°C | |
| Protection Level | IP54 | |
| Reductor Type | Irreversible | |
| Opening Time at 90° | 4 - 8 sec | |
| Onboard Control Unit | CTRL Digital Controller 36V DC | |
| Encoder | Digital native encoder + magnetic digital SENSORED, 4096 PPR | |
| Accessories Power Supply | 24V DC | |
| Colour | Cabinet: painted RAL9006 arabesque grey; Head: black arabesque silver painted; Boom support: black arabesque silver painted; Boom: painted RAL9010 matt | Cabinet: brushed stainless steel AISI 304; Head: black arabesque silver painted; Boom support: black arabesque silver painted; Boom: painted RAL9010 matt |
| Release System | European Key cylinder | |
| Batteries Recovery | Available (optional) | |
| BUS Synchronization Master/Slave | Yes | |
| Operating Cycles per Day | 4000 cycles | |
| Maximum Dimension Product (L x W x H) | 380 x 270 x 1237 mm | |
| Product Weight Packed | 75.1 Kg | 73.6 Kg |
Accessories
Below are the accessories suitable for the BI/006 Series:
- KT230: Fixing plate for various models
- B73/EXP: Signal status board for CTRL units
- SP/72/01: Spring for barriers
- BT12V45: Battery
- DLD1/24: Single loop detector
- DLD2/24: Dual loop detector
- ALED/4C: LED strip for barrier boom
- BI/BAT/KIT: Emergency battery charger kit for BIONIK barriers
- BI/BCHP: Charger card for BIONIK barriers
- KT239: DIN rail kit with magnetic support
- KT242: Cable passage kit for barriers
- CRA/BAR: Post for photocells on barrier
- ACS/BA/60: Break-away system for BA/60/3 boom arm
- R99/BASB20: Stickers pack for barriers
- B74/BCONNECT: Wi-Fi module for remote management
- B71/PBX36/BOX/115: Hybrid inverter for 36V DC controllers, 115V AC
- B71/PBX36/BOX: Hybrid inverter for 36V DC controllers, 230V AC
- B71/PBX/BOX: Hybrid inverter for brushless digital controllers, solar version
- ACS/BA/68: Break-away system for BA/68 boom arms
- CRA/BAR/M90: Post for M90 photocells on barrier
- BA/91/3: Aluminum rod for barriers with LED and rubber profile
- JNT/BA/91: Internal boom bar joint
- SND/BA/91/DW: Articulated joint with lower tie rod
- SND/BA/91/UP: Articulated joint with upper tie rod
Additional Information
For more details on the BI/006 Series Bionik Brushless Barriers or to place an order, please contact us. Our team is ready to assist you with any questions or support you may need.
